Six disciplines, one integrated workshop.
From CAD design to composite layup and final QA — every step of the manufacturing process happens in-house. That keeps communication tight, lead times short, and quality consistent across marine, aviation, automotive, and industrial clients.
5-Axis CNC Machining
Large Gantry CNC
Our 5-axis gantry handles formats up to 6 × 2.5 × 1.5 m in a single setup — ideal for marine tooling, architectural scale models, and large automotive masters.
Read more3D CNC Machining
Multi-axis 3D profile cutting for complex mold surfaces and prototype geometries. We work in tooling board, hardwoods, aluminium, and modelling foam.
Read moreSub-millimeter Tolerances
Calibrated tooling and in-process measurement with calibrated touch probes. Standard ±0.1 mm on steel, ±0.2 mm on tooling board and composites.
Read more5-Axis CNC Machining — in detail
Our flagship service. The 5-axis gantry at our Kaštel Novi workshop is the largest of its class in the region — capable of single-setup machining across formats that would normally require repositioning or multiple CNC passes. That means faster turnaround, fewer seams, and tighter tolerance on complex free-form surfaces.
Capacity
- Working volume: 6.0 × 2.5 × 1.5 m
- 5-axis continuous simultaneous
- Spindle: 18 kW, 24 000 RPM
- Tool magazine: 24 positions
- Vacuum table + T-slot hybrid bed
Materials we cut
- Tooling board (Renshape, Precision Board)
- Aluminium alloys (5083, 6082, 7075)
- Stainless & mild steel
- Phenolic, plywood, hardwood
- Modelling foam (PU, EPS)
Typical tolerances
- Tooling board: ±0.2 mm
- Aluminium: ±0.1 mm
- Steel: ±0.1 mm
- Free-form surfaces: ±0.5 mm over 5 m
- In-process measurement at every setup
Typical applications
- Marine hull & deck tooling plugs
- Aviation interior trim masters
- Automotive prototype panels
- Architectural concrete molds
- Industrial machine covers
Vacuum Infusion
Closed-Mold Infusion
Consistent fiber volume, low void content, repeatable serial production for marine and aviation parts. Cycle time depends on part size and laminate thickness.
Read moreRobotic Layup
Two robotic arms handling ply placement for serial production runs — reduces cycle time by up to 60 % versus hand layup and improves ply-position repeatability.
Read moreHand Layup & Repair
For complex one-offs and legacy component repair — our composite technicians handle the work the robots can't, including structural repairs and legacy parts.
Read moreVacuum Infusion & Composite Layup — in detail
Vacuum infusion is our primary process for serial-production composite parts. We start with a closed mold (typically machined on our 5-axis CNC), place dry fabric reinforcement, seal under vacuum bag, and pull resin through the laminate under atmospheric pressure. The result: consistent fiber volume, low void content, and excellent mechanical properties.
Process variants
- VARTM (Vacuum-Assisted RTM)
- Light RTM
- Standard vacuum infusion
- Wet layup with vacuum bag
- Autoclave cure (for aerospace)
Resin systems
- Polyester (ortho & iso)
- Vinylester (Derakane, Atlac)
- Epoxy (DGEBA, toughened)
- High-temperature epoxy for autoclave
- Fire-retardant systems
Tooling
- 5-axis machined molds (aluminium, tooling board)
- Composite layup molds
- Nickel-shell electroformed molds (select projects)
- In-house mold design & build
Quality control
- Vacuum leak test before every infusion
- In-process temperature & pressure logging
- Ultrasonic NDT on critical parts
- FAI dimensional report per project
- Material certificates retained
Advanced Materials
Carbon Fiber
Prepreg and dry carbon layup with autoclave or vacuum-bag cure cycles. We work with 3K twill, unidirectional, and stitched multiaxial fabrics across aerospace and motorsport.
Read moreKevlar & Aramid
Ballistic and impact-resistant layups for marine, security, and motorsport applications. Hybrid layups (carbon + aramid) common for impact-critical parts.
Read moreBasalt Fiber
Sustainable mineral-fiber alternative with excellent mechanical properties and thermal stability. Growing demand in construction and transportation.
Read moreAdvanced Materials — in detail
Material selection drives everything downstream — weight, cost, mechanical performance, finish quality, and lifecycle. We help clients choose the right reinforcement for the application, then execute with the process best suited to that material. Below is what we work with day-to-day.
Carbon fiber
- 3K twill, 1K, 6K, 12K weaves
- Unidirectional (UD) tapes
- Stitched multiaxial NCF
- Prepreg (autoclave & oven cure)
- Dry fabric for infusion
- Recycled carbon (select programs)
Kevlar / Aramid
- Kevlar 49 (high-modulus)
- Kevlar 29 (impact)
- Twaron, Technora alternatives
- Hybrid layups (carbon + aramid)
- Common in marine fenders, security
Basalt fiber
- Mineral-fiber reinforcement
- Higher temperature tolerance than E-glass
- Non-flammable, no toxic smoke
- Sustainable (basalt rock feedstock)
- Construction, transportation, fire
Fiberglass & hybrids
- E-glass (standard & high-strength)
- S-glass (aerospace-grade)
- Core materials (PVC foam, end-grain balsa, Nomex honeycomb)
- Sandwich constructions
- Coated & treated fabrics
CAD / CAM
CAD Modeling
Solid and surface modeling in Fusion 360, Rhinoceros, and Mastercam — export-ready for any CNC. We work from your sketches, PDFs, or native CAD files.
Read moreToolpath Programming
Multi-axis toolpath generation, simulation, and verification before a single chip is cut. We optimise for cycle time, surface quality, and tool life.
Read moreDFM Review
Design-for-manufacturing feedback on your geometry — before tooling investment. Saves weeks of rework and protects the timeline on tight programs.
Read moreCAD / CAM Engineering — in detail
Every part we manufacture starts in CAD. Our engineering team models your design intent, validates it for manufacturability, and programs the toolpaths that drive our CNC. This is where most program risk lives — get it right here, and the rest of the project runs smoothly.
Tools we use
- Fusion 360 (CAD + CAM)
- Rhinoceros 7 + Grasshopper
- Mastercam 2024
- SolidWorks (read/write)
- AutoCAD (read)
- ZW3D, CATIA on request
File formats accepted
- STEP, IGES, Parasolid (preferred)
- Native Fusion, Rhino, Mastercam
- SolidWorks, CATIA, NX
- 2D drawings: PDF, DXF
- Point clouds / mesh: STL, OBJ, PLY
- Scanned surfaces reverse-modelled
Deliverables
- 3D CAD model (parametric)
- Class-A surface model
- Manufacturing drawings (GD&T)
- Verified CNC toolpath files
- DFM review report
- Material & process specification
Why DFM matters
- Catches manufacturability issues early
- Identifies cost drivers
- Suggests geometry simplifications
- Validates tolerance feasibility
- Often saves weeks of rework
- Included with every quote
Quality Assurance
Dimensional Inspection
In-process measurement with calibrated probes. Every part signed off against your drawing — full dimensional report attached to delivery.
Read moreFinal QC Report
Full dimensional report attached to each delivery — supports your own incoming inspection and meets regulated-industry documentation requirements.
Read moreDocumentation Trail
Material certificates, process records, and traceability maintained for regulated industries. FAI, cure-cycle data, and NDT reports available on request.
Read moreQuality Assurance — in detail
QA isn't a department here — it's the last step of every operation. From incoming material inspection to in-process measurement to final dimensional check, our QA team is integrated with production. Aerospace and marine tier-1 programs run on documentation; we maintain the trail end-to-end.
In-process inspection
- Touch-probe dimensional check at every setup
- Tool wear monitoring
- Cure-cycle temperature logging (composites)
- Vacuum leak test before every infusion
- Visual inspection at every stage
Final inspection
- CMM dimensional verification
- Surface roughness measurement
- Visual finish check vs reference
- FAI dimensional report (PDF)
- Material certificate attached
NDT (non-destructive testing)
- Ultrasonic testing (UT)
- Visual NDT
- Tap-test (composites)
- Partner labs for X-ray, thermography
- Reports issued per program spec
Documentation
- First-article inspection (FAI)
- Material certificates (CoC)
- Process / cure records
- Calibration records (probes, scales)
- Full traceability per part
Precision Engineering
Mechanical Engineering
Conceptual design, structural analysis, and prototype builds. We support client engineering teams or take a brief and run with it — your call.
Read moreReverse Engineering
Scanned legacy parts re-modelled in CAD. Useful when original drawings are lost, or when you need to re-create a tool for a part that no longer has documentation.
Read morePrototype Engineering
Single-piece prototypes to validate form, fit, and function before tooling investment. Fast iteration cycles, in-house CNC and layup.
Read morePrecision Engineering — in detail
For clients without in-house engineering depth, we step in as the engineering partner. For clients with engineering teams, we work as an extension — DFM review, toolpath programming, structural analysis. Either way, the goal is the same: a part that can be built, on schedule, at the right cost.
Concept & design
- Industrial design support
- Mechanical engineering (CAD, FEA)
- Material selection guidance
- Cost & manufacturability analysis
- Concept prototypes
Structural analysis
- FEA on critical load paths
- Layup schedule optimisation
- Core thickness selection
- Impact & fatigue considerations
- Partner labs for validation testing
Reverse engineering
- 3D scanning (partner service)
- Mesh-to-CAD re-modelling
- Legacy part reproduction
- Tooling re-creation
- Drawing & spec regeneration
Prototype development
- Single-piece prototypes
- Pre-production runs (5–20 units)
- Design validation
- Form, fit, function testing
- Iterative refinement cycles
Not sure which service fits?
Send us your brief. We'll route it to the right engineer and respond within one business day.
